Product Description Of EP4CGX30CF23I7N

EP4CGX30CF23I7N is Cyclone® IV GX Field Programmable Gate Array IC. It is lowest power and lowest cost FPGAs with 3.125 Gbps transceivers

EP4CGX30CF23I7N——Cyclone® IV GX devices offer an on-chip transceiver with an I/Os speed up to 3.125Gbps. This high-speed transceiver supports many serial I/O protocols, such as Gigabit Ethernet (GbE), PCI Express (PCIe), CPRI, XAUI, 3G Triple-Rate SDI, Serial RapidIO®, SATA, DisplayPort, and V-by-One, that are migrating from the cutting edge to the mainstream. Cyclone® IV GX FPGAs also include an embedded PCIe hard IP block that, when utilized by the design engineer, does not use any of the FPGA logic and supports more functionality than many other competing FPGA architectures.

Specification Of EP4CGX30CF23I7N

Features Of EP4CGX30CF23I7N

Up to eight high-speed transceivers that provide:
- Data rates up to 3.125 Gbps
- 8B/10B encoder/decoder
- 8-bit or 10-bit physical media attachment (PMA) to physical coding sublayer (PCS) interface
Dedicated hard IP for PCI Express (PIPE) (PCIe) Gen 1:
- ×1, ×2, and ×4 lane configurations
- End-point and root-port configurations
- Up to 256-byte payload
Wide range of protocol support:
- PCIe (PIPE) Gen 1 ×1, ×2, and ×4 (2.5Gbps)
- Gigabit Ethernet (1.25Gbps)
- CPRI (up to 3.072Gbps)

Applications Of EP4CGX30CF23I7N
Broadcast
Consumer
Industrial
Wireless
Wireline
