ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets
ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

Gambar besar :  ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: ASPI0001-P001A
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: 8POS
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

Deskripsi
Nomor bagian: ASPI0001-P001A Tinjauan Produk: SPI 8PIN_IC 150mil
Peringkat saat ini: 1a Max. Voltase: 12v
Max. Suhu proses: 260 ℃ Jumlah Posisi atau Pin (Kisi): 8 (2 x 4) pos
Menyoroti:

SPI socket 8 position connector

,

8 pin IC socket 150mil

,

12V 1A SPI connector

ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

ASPI0001-P001A Connectors SPI Socket 8POS SPI 8Pin_IC 150mil 12V 1A IC Sockets

Product Description

ASPI0001-P001A is SPI Socket (SPI 8Pin_IC 150mil) - 8 (2 x 4) Pos, SOIC Socket, Gold Surface Mount.

Specifications
Type SOIC
Number of Positions or Pins (Grid) 8 (2 x 4)
Pitch - Mating 0.050" (1.27mm)
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 1.00µin (0.025µm)
Contact Material - Mating Phosphor Bronze
Mounting Type Surface Mount
Features Board Guide, Closed Frame
Termination Solder
Pitch - Post 0.050" (1.27mm)
Contact Finish - Post Gold
Contact Finish Thickness - Post 1.00µin (0.025µm)
Contact Material - Post Phosphor Bronze
Housing Material Liquid Crystal Polymer (LCP)
Material Flammability Rating UL94 V-0
Contact Resistance 30mOhm
Features
General Characteristic
  • Product Overview: SPI 8Pin_IC 150mil
  • Component Type: Receptacle
  • PCB Mount Type: SMT
  • Orientation: Vertical
Physical Characteristic
  • Housing Material: LCP
  • Contact Material: C2680
  • Plating Material on Contact Area: Au
  • Plating Thickness on Contact Area: G/F
  • Circuits: 16 pin
  • Pitch: 1.27mm
  • Tail Length: 1mm
  • Durability: 25 Cycles
  • Housing Color: Black
Electrical Characteristic
  • Current Rating: 1A
  • Max. Voltage: 12V
Solder Process Characteristic
  • Solder Process Type: IR Reflow
  • Max. Process Temperature: 260℃
  • Duration at Max. Process Temperature: 10s
