TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator

TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator
TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator

Gambar besar :  TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: TPS25200QDRVRQ1
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: WSON-6
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator

Deskripsi
Nomor bagian: TPS25200QDRVRQ1 Batas saat ini: 2.7 A
Arus pasokan operasi: 147 ua Jumlah saluran: 1 saluran
Suhu operasi: -40°C ~ 125°C (TJ) Kategori produk: Pengendali tegangan swap panas

TPS25200QDRVRQ1 Integrated Circuit Chip Automotive eFuse WSON6 Electronic Fuse Regulator​



Product Description Of TPS25200QDRVRQ1

TPS25200QDRVRQ1 is a 5V eFuse with a precision current-limit and overvoltage clamp. The device provides robust protection for load and source during overvoltage and overcurrent events.
TPS25200QDRVRQ1 is an intelligent protected load-switch with a VIN value tolerant to 20 V. In the event that an incorrect voltage is applied at the IN pin, the output clamps to 5.4 V to protect the load. If the voltage at the IN pin exceeds 7.6 V, the device disconnects the load to prevent damage to the device, load, or both.


Specification Of TPS25200QDRVRQ1

Function
Electronic Fuse
Accuracy
±6.3%
Voltage - Input
2.5V ~ 6.5V
Current - Output
2.4A
Operating Temperature
-40°C ~ 125°C (TJ)
Grade
Automotive
Qualification
AEC-Q100
Mounting Type
Surface Mount
Package / Case
6-WDFN Exposed Pad
Supplier Device Package
6-WSON (2x2)


Features Of TPS25200QDRVRQ1

2.5V to 6.5V Operation
20V Continuous VIN (Absolute Maximum)
7.6V Input Overvoltage Shutoff
5.25V to 5.55V Fixed Overvoltge Clamp
0.6µs Overvoltage Lockout Response
3.5µs Short-Circuit Response
67mΩ High-Side MOSFET
Accurate 2.5A Minimum, 2.9A Maximum and 2.1A Minimum, 2.5A Maximum Setting (Including Resistor)
±6.3% Current-Limit Accuracy at 2.7A
Reverse Current Blocking While Disabled
Built-in Soft Start
Pin-to-Pin Compatible with TPS2553


Applications Of TPS25200QDRVRQ1

Automotive USB Port Protection
USB Power Switch
USB Slave Devices


Other Electronic Components In Stock

Part Number Package
IPT012N08NF2S PG-HSOF-8
IPD055N08NF2S TO-252-3
PB043N10NF2S TO-263-3
IPP015N04NF2S TO-220-3
IPD040N08NF2S TO-252-3
IPF050N10NF2S TO-263-7
IPB023N04NF2S TO-263-3
IPF010N04NF2S TO-263-7
IPF013N04NF2S TO-263-7
IPF016N06NF2S TO-263-7
IPB015N06NF2S TO-263-3
IPF010N06NF2S TO-263-7
IPB012N04NF2S TO-263-3
IPB029N06NF2S TO-263-3
IPF012N06NF2S PG-TO263-7
IPB014N04NF2S TO-263-3
IPB011N04NF2S TO-263-3
IPB013N06NF2S TO-263-3
IPB018N06NF2S TO-263-3
IPF042N10NF2S PG-TO263-7
IPD028N06NF2S TO252-3
IPP013N04NF2S TO-220-3
IPP014N06NF2S TO-220-3
IPF017N08NF2S PG-TO263-7
IPP016N06NF2S TO-220-3
IPP019N06NF2S TO-220-3
IPP030N06NF2S TO-220-3
IPF023N08NF2S PG-TO263-7
IPF039N08NF2S PG-TO263-7
IPB024N08NF2S TO-263-3


FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
