TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C

TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C
TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C

Gambar besar :  TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: TLE7184F
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: VQFN-48
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

TLE7184F MOTIX System IC Integrated Circuit Chip with 5V Vreg-Controller for B6 Motor Drives 6V-45V Supply -40°C to 150°C

Deskripsi
Nomor bagian: TLE7184F Arus pasokan operasi: 19 mA
Tegangan - Pasokan: 6V ~ 45V Konfigurasi: Tiga fase
Kelas Tegangan: 55 V Suhu operasi: -40°C ~ 150°C (TJ)
Menyoroti:

Integrated 5V Vreg-Controller System IC

,

6V ~ 45V Supply Voltage Integrated Circuit Chip

,

-40°C ~ 150°C Operating Temperature MOTIX IC

TLE7184F Integrated Circuit Chip MOTIX System IC For B6 Motor Drives VQFN48
Product Description

MOTIX™ TLE7184F is a system IC with 3-phase driver and an integrated 5V Vreg-controller to power a MCU.

The MOTIX™ TLE7184F is a system IC for Brushless Motor Control. It incorporates a voltage supply for a µC, a bridge driver for a B6 configuration, and an application typical PWM interface. Its exposed pad package allows usage even at high ambient temperatures.

Specifications
Motor Type AC, DC | Brushless DC (BLDC), Brushed DC
Function Controller - Commutation, Direction Management
Output Configuration Pre-Driver - Half Bridge (3)
Interface PWM
Technology Power MOSFET
Voltage - Supply 6V ~ 45V
Operating Temperature -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 48-VQFN Exposed Pad
Supplier Device Package PG-VQFN-48-72
Key Features
  • Drives 6 N-Channel Power MOSFETs
  • Integrated 5V Vreg-Controller to power µC
  • Integrated switch for VDH voltage
  • Separate control input for each MOSFET
  • Adjustable dead time
  • Shoot through protection
  • Analog adjustable Short Circuit Protection levels
  • Low quiescent current mode
  • 1 bit diagnosis ERR
  • Over Temperature shut down and analog temperature output
  • Over Temperature pre-warning
  • Under Voltage shut down
  • Adjustable Over Voltage shut down
  • Current sense OpAmp
  • Over current shut down based on Current sense OpAmp, fixed shut down level
  • 0 …94% duty cycle at 25 kHz PWM frequency
