STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory
STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Gambar besar :  STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: STM32L031F6P6
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: TSSOP-20
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

STM32L031F6P6 Microcontroller MCU 32-Bit ARM Cortex-M0+ with 32MHz Clock and 32 kB Flash Memory

Deskripsi
Nomor bagian: STM32L031F6P6 Inti:: ARM Korteks M0+
Ukuran Memori Program:: 32 kb Lebar bus data:: 32 bit
Resolusi ADC:: 12 bit Frekuensi jam maksimum:: 32 MHz
Menyoroti:

32-Bit Microcontroller MCU

,

32MHz ARM Cortex-M0+

,

32 kB Flash STM32L031F6P6

STM32L031F6P6 Microcontroller MCU 32-Bit 32MHz ARM Cortex-M0+
Product Overview
The STM32L031F6P6 is an access line ultra-low-power microcontroller incorporating the high-performance ARM® Cortex®-M0+ 32-bit RISC core operating at 32 MHz. It features high-speed embedded memories (up to 32KB Flash, 1KB EEPROM, and 8KB RAM) along with enhanced I/Os and peripherals. Designed for power efficiency, it offers multiple low-power modes and clock source options.
Key Specifications
Core Processor ARM® Cortex®-M0+
Core Size 32-Bit
Speed 32MHz
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Number of I/O 15
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
EEPROM Size 1K x 8
RAM Size 8K x 8
Voltage Supply 1.8V ~ 3.6V
Data Converters A/D 10x12b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Key Features
  • Ultra-low-power platform (1.65V to 3.6V power supply)
  • 0.25 μA Standby mode (2 wakeup pins)
  • 0.38 μA Stop mode (16 wakeup lines)
  • 0.68 μA Stop mode with RTC + 8KB RAM retention
  • 76 μA/MHz in Run mode
  • 5 μs wakeup time (from Flash memory)
  • 41 μA 12-bit ADC conversion (at 10ksps)
  • ARM® 32-bit Cortex®-M0+ core (0.95 DMIPS/MHz)
  • Multiple clock sources including crystal oscillators and internal RC
  • Up to 38 fast I/Os (31 I/Os 5V tolerant)
  • Rich analog peripherals including 12-bit ADC and comparators
  • Multiple communication interfaces (USART, SPI, I2C)
  • 8 timers including ultra-low-power timer and watchdogs
