IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone

IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone
IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone

Gambar besar :  IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: IM69D127V11
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: LGA-4
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone

Deskripsi
Nomor Bagian: IM69D127V11 Kepekaan:: - 35dB
Toleransi:: 1 dB SNR - Rasio Sinyal terhadap Kebisingan:: 69 dB
Rentang frekuensi:: 40Hz hingga 15kHz Tegangan suplai operasi:: 1,62 V hingga 3,6 V
Menyoroti:

PDM MEMS microphone sensor IC

,

ultra-high performance digital microphone

,

IM69D127V11 MEMS microphone IC

IM69D127V11 Sensor IC Ultra-High Performance Digital PDM MEMS Microphone
The IM69D127V11 is an ultra-high performance digital PDM MEMS microphone designed for applications requiring exceptional SNR (low self-noise), minimal distortion (high AOP), and IP57-rated dust/water resistance.
Key Specifications
Type MEMS (Silicon)
Output Type Digital, PDM
Direction Noise Cancelling
Frequency Range 20 Hz ~ 20 kHz
S/N Ratio 69dB
Port Location Bottom
Size/Dimension 0.142" L x 0.098" W (3.60mm x 2.50mm)
Height (Max) 0.039" (1.00mm)
Shape Rectangular
Advanced Features
  • Component level IP57 dust and water resistance
  • 102dB dynamic range with 69dB(A) signal-to-noise ratio
  • Less than 1% total harmonic distortion up to 123dBSPL
  • 127dBSPL acoustic overload point
  • ±1dB sensitivity matching for beamforming applications
  • Flat frequency response with 40Hz low frequency rolloff
  • Power optimized modes via PDM clock frequency
  • Compact 3.60mm * 2.50mm * 1.00mm package
  • PDM output with omnidirectional pickup pattern
Recommended Applications
  • Active Noise Cancellation (ANC) headphones and wireless earbuds
  • Voice User Interface (VUI) devices:
    • Smart speakers
    • Home automation systems
    • IoT devices
  • High-quality audio capture for:
    • Cameras
    • Laptops and tablets
    • Conference systems
