G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating
G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Gambar besar :  G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Detail produk:
Tempat asal: Cn
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: G46M2023201BWEU
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: 20POS
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Deskripsi
Nomor Bagian: G46M2023201BWEU Resistansi Konduktor Awal: 10mΩ maks
Hubungi Peringkat Saat Ini: 0,5A Menit Tegangan menahan dielektrik: 500V AC (RMS)
Kemasan: 20 Posisi Jenis: Sistem Konektor DisplayPort
Menyoroti:

DisplayPort 1.4 compliant DisplayPort Connector

,

500V AC(RMS) Dielectric Withstanding DisplayPort Connector

,

0.5A Contact Current Rating DisplayPort Connector

G46M2023201BWEU Connectors G46 Series DisplayPort Connector System 20 Position
Product Description
The G46M2023201BWEU DisplayPort connector system is a scalable solution that transmits 1, 2 or 4 lanes of High-Definition video at 2.7Gb/s per lane up to a maximum of 10.8Gb/s. DisplayPort also allows flexible allocation of available bandwidth between audio and video.
Specifications
Housing High Temperature Thermoplastic, complies with UL 94V-0, Black
Conductor Resistance Initial 10mΩ max.
Shell Initial Contact Resistance 30mΩ max.
Contact Current Rating 0.5A min.
Dielectric Withstanding Voltage 500V AC(RMS)
Humidity 4 cycles between +25°C to +85°C, Relative Humidity 80% to 95%
Thermal Shock 10 cycles between -55˚C to +85˚C
Features
  • DisplayPort 1.4 compliant
  • Protects against ESD (Electrostatic discharge) and EMI (Electromagnetic Interference)
  • Self-latching connector
  • Fully shielded metal shell
  • Fully backward compatible with earlier HDMI
  • Miniaturized option available: Mini DisplayPort
Benefits
  • Performs at 2.7Gb/s per lane backward compatible with earlier DisplayPort product
  • Ensures quick and stable connections
  • Protects against ESD and EMI
  • Meets environmental, health and safety requirements
Applications
  • Datacommunication equipment
  • Telecommunications
  • High End Computers
  • Servers
  • Test Card and Card Extenders
