ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Gambar besar : ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Detail produk:

Tempat asal:	CN
Nama merek:	Original Factory
Sertifikasi:	Lead free / RoHS Compliant
Nomor model:	ACPL-247-500E

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	10
Harga:	Contact for Sample
Kemasan rincian:	SO-16
Waktu pengiriman:	5-8 HARI KERJA
Syarat-syarat pembayaran:	T/T, L/C, Western Union

Kontak

ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Deskripsi

Nomor bagian:	ACPL-247-500E	Jumlah Saluran:	4 saluran
Tegangan isolasi:	3750 Vrm	Jika - Maju Arus:	50 ma
Vf - Tegangan Maju:	1,4 V	Pd - Pembuangan Daya:	170 mW
Menyoroti:	Quad-Channel Optocoupler , 3750 Vrms Isolation Voltage Optocoupler , 50 mA Forward Current Phototransistor

ACPL-247-500E Integrated Circuit Chip Quad-Channel Half-Pitch Phototransistor Optocoupler

The ACPL-247-500E is a DC-input dual channel half-pitch phototransistor optocoupler featuring two light emitting diodes optically coupled to two separate phototransistors. This component offers input-output isolation voltage rated at 3,000 VRMS and typical response time of 2μs, with minimum CTR of 100% at IF 5mA.

Technical Specifications

Number of Channels	4
Voltage - Isolation	3000Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	600% @ 5mA
Turn On / Turn Off Time (Typ)	3µs, 3µs
Rise / Fall Time (Typ)	2µs, 3µs
Input Type	DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	50 mA
Vce Saturation (Max)	400mV
Operating Temperature	-55°C ~ 110°C
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.173", 4.40mm Width)
Supplier Device Package	16-SO

Key Features

Current transfer ratio (CTR): 50% (min) at IF = 5mA, VCE = 5V
High input-output isolation voltage (VISO = 3,000VRMS)
Non-saturated response time (tr: 2μs typ at VCC = 10V, IC = 2mA, RL= 100Ω)
SO package design
CMR 10kV/μs (typical)

Applications

I/O Interface for Programmable controllers and computers
Sequence controllers
System appliances and measuring instruments
Signal transmission between circuits of different potentials and impedances
