XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169

XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169
XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169 XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169

Gambar besar :  XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169

Detail produk:
Tempat asal: CN
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: XIO2001ZWS
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: NFBGA-169
Waktu pengiriman: 5-8 HARI KERJA
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

XIO2001ZWS Integrated Circuit Chip PCI Express to PCI Bridge with 125 MHz Maximum Clock Frequency 1 Lane and Surface Mount NFBGA169

Deskripsi
Nomor bagian: XIO2001ZWS Jenis: Jembatan - PCIe ke PCI
Frekuensi jam maksimum: 125 MHz Jumlah Jalur: 1 jalur
Jumlah port: 1 port Suhu Operasional: -40 ° C ~ 85 ° C.
Menyoroti:

125 MHz Maximum Clock Frequency Integrated Circuit Chip

,

1 Lane PCI Express Bridge

,

Surface Mount NFBGA169

XIO2001ZWS Integrated Circuit Chip PCI Express To PCI Bus Translation Bridge NFBGA169
The XIO2001ZWS is a single-function PCI Express to PCI translation bridge that is fully compliant to the PCI Express to PCI/PCI-X Bridge Specification, Revision 1.0. For downstream traffic, the bridge simultaneously supports up to eight posted and four non-posted transactions. For upstream traffic, up to six posted and four non-posted transactions are simultaneously supported.
Specifications
Applications PCI Express to PCI Translation Bridge
Interface PCI Express
Voltage - Supply 1.35V ~ 1.65V, 3V ~ 3.6V
Package / Case 169-LFBGA
Supplier Device Package 169-NFBGA (12x12)
Mounting Type Surface Mount
Key Features
  • Full *1 PCI Express™ Throughput
  • Fully Compliant With PCI Express to PCI/PCI-X Bridge Specification, Revision 1.0
  • Fully Compliant With PCI Express Base Specification, Revision 2.0
  • Fully Compliant With PCI Local Bus Specification, Revision 2.3
  • PCI Express Advanced Error Reporting Capability Including ECRC Support
  • Support for D1, D2, D3hot, and D3cold
  • Active-State Link Power Management Saves Power When Packet Activity on the PCI Express Link is Idle, Using Both L0s and L1 States
  • Wake Event and Beacon Support
  • Error Forwarding Including PCI Express Data Poisoning and PCI Bus Parity Errors
  • Uses 100-MHz Differential PCI Express Common Reference Clock or 125-MHz Single-Ended, Reference Clock
  • Optional Spread Spectrum Reference Clock is Supported
  • Robust Pipeline Architecture to Minimize Transaction Latency
  • Full PCI Local Bus 66-MHz/32-Bit Throughput
  • Support for Six Subordinate PCI Bus Masters with Internal Configurable, 2-Level Prioritization Scheme
  • Internal PCI Arbiter Supporting Up to 6 External PCI Masters
  • Advanced PCI Express Message Signaled Interrupt Generation for Serial IRQ Interrupts
  • Clock Run and Power Override Support
  • Six Buffered PCI Clock Outputs (25 MHz, 33 MHz, 50 MHz, or 66 MHz)
  • PCI Bus Interface 3.3-V and 5.0-V (25 MHz or 33 MHz only at 5.0 V) Tolerance Options
  • Integrated AUX Power Switch Drains VAUX Power Only When Main Power Is Off
  • Five 3.3-V, Multifunction, General-Purpose I/O Terminals
  • Memory-Mapped EEPROM Serial-Bus Controller Supporting PCI Express Power Budget/Limit Extensions for Add-In Cards
Applications
  • Enterprise systems: Data center & enterprise computing
  • Personal electronics: PC and notebooks
  • Industrial applications: Factory automation and control, Retail automation & payment, Industrial transport (non-car & non-light truck)
