HCNW3120-500E Integrated Circuit Chip 2.5A Output Current IGBT Gate Drive Optocoupler

HCNW3120-500E contains a GaAsP LED while the HCPL-J312 and the HCNW3120-500E contain an AIGaAs LED. The LED is optically coupled to an integrated circuit with a power output stage. These optocouplers are ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications.

The high operating voltage range of the output stage provides the drive voltages required by gate controlled devices. The voltage and current supplied by these optocouplers make them ideally suited for directly driving IGBTs with ratings up to 1200V/100A. For IGBTs with higher ratings, the HCPL-3120 series can be used to drive a discrete power stage, which drives the IGBT gate.

• 2.5A maximum peak output current
• 2.0A minimum peak output current
• 25 kV/us minimum common mode rejection (CMR) at VcM= 1500V
• 0.5V maximum low-level output voltage(VoL) eliminates need for negative gate drive
• Icc = 5 mA maximum supply current
• Under-voltage lockout protection (UVLO) with hysteresis
• Wide operating Vcc range: 15V to 30V
• 500_ns maximum switching speeds
• Industrial temperature range: -40°C to +100°C

• IGBT/MOSFET gate drive
• AC/Brushless DC motor drives
• Industrial inverters
• Switch mode power supplies
