ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit

ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit
ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit

Gambar besar :  ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit

Detail produk:
Tempat asal: CN
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: ICM-40605
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: LGA
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit

Deskripsi
Nomor Bagian: ICM-40605 Sumbu: 6-sumbu
Catu Daya VDD: 1.71V sampai 3.6V Kesalahan Sensitivitas Gyro: ±0,5%
Kebisingan Aksel: 100μg/√Hz Kisaran suhu pengoperasian: -40 ℃ hingga +85 ℃

ICM-40605 Sensor IC Low Power 6-Axis MotionTracking Device 6-Axis MEMS Inertial Measurement Unit

ICM-40605 is a 6-axis MotionTracking chip launched by TDK (formerly InvenSense). It integrates a 3-axis gyroscope and a 3-axis accelerometer in an ultra-compact LGA package, and is designed for low noise, low power consumption and high stability. It is intended for high-precision attitude detection applications in consumer electronics, drones, wearable devices and lightweight industrial control systems.

Specifications
Parameter Value
Digital Output I2C, SPI
VDD Power Supply 1.71 to 3.6 V
VDDIO I/O Power Supply 1.71 to 3.6 V
Gyro FSR ±15.625/31.25/62.5/125/250/500/1000/2000
Gyro Sensitivity Error ±0.5%
Gyro Rate Noise 0.0038 dps/√Hz
Accel FSR ±2/4/8/16
Accel Sensitivity Error ±0.5%
Accel Noise 100 μg/√Hz
Key Features
  • Supply Voltage: VDD = 1.71-3.6 V; VDDIO = 1.71-3.6 V (separate I/O power supply)
  • Temperature Range: -40°C to 85°C (commercial grade)
  • Gyroscope (3-axis): Measurement range: ±15.625/31.25/62.25/125/250/500/1000/2000 dps (8 programmable levels)
  • Gyroscope Noise density: 0.0038 dps/√Hz (low-noise mode)
  • Gyroscope Sensitivity error: ±0.5%
  • Gyroscope Resolution: 16-bit ADC
  • Gyroscope Bandwidth: Programmable low-pass filter (5-250 Hz)
  • Accelerometer (3-axis): Measurement range: ±2/4/8/16 g (4 programmable ranges)
  • Accelerometer Noise density: 70 µg/√Hz
  • Accelerometer Sensitivity error: ±0.5%
  • Accelerometer Resolution: 16-bit ADC
  • Accelerometer Bandwidth: Programmable low-pass filter
  • Memory: FIFO: 1 KB (reduces bus load and system power consumption)
  • Communication interfaces: I²C: Up to 1 MHz, SPI: Up to 8 MHz
  • Interrupts: Data ready, FIFO full, motion wake-up, free-fall detection
  • Power Consumption: Low-noise mode: 0.65 mA, Low-power accelerometer mode: ≈1.5 µA, Sleep mode: <1 µA
  • Built-in temperature sensor (±1°C accuracy)
  • Hardware self-calibration, temperature compensation
  • Supports motion wake-up (WOM), pedometer, tilt detection, tap detection
  • Highly vibration- and shock-resistant design
Applications
  • Smartphones / Tablets: Auto-rotate screen, image stabilisation, gaming posture control, navigation assistance
  • Smartwatches / Fitness Bands: Activity tracking, step counting, sleep analysis, gesture recognition
  • VR/AR headsets / controllers: Head / hand posture tracking, anti-shake
  • Consumer drones / model aircraft: Flight control attitude stabilisation, gimbal stabilisation
  • TWS earphones: Wear detection, in-ear detection, spatial audio positioning
  • IoT devices / smart hardware: Motion wake-up, status monitoring, anti-theft alarm
  • Lightweight industrial / robotics: Posture detection, vibration monitoring, balance control
