Product Description Of TDA8547TS
TDA8547TS is a two channel audio power amplifier for an output power of 2 x 0.7 W with a 16 Ω load at a 5 V supply. At a low supply voltage of 3.3 V an output power of 0.6 W with an 8 W load can be obtained. The circuit contains two BTL amplifiers with a complementary PNP-NPN output stage and standby/mute logic.

Specification Of TDA8547TS

Features Of TDA8547TS
Selection between output channels
Flexibility in use
Few external components
Low saturation voltage of output stage
Gain can be fixed with external resistors
Standby mode controlled by CMOS compatible levels
Low standby current
No switch-on/switch-off plops
High supply voltage ripple rejection
Protected against electrostatic discharge
Outputs short-circuit safe to ground, VCC and across the load
Thermally protected

Applications Of TDA8547TS
Telecommunication equipment
Portable consumer products
Personal computers
Motor-driver (servo)
