TPS7A4001DGNR 100V Input 50mA Output Low-Dropout Voltage Regulator with HVSSOP-8 Package

Gambar besar : TPS7A4001DGNR 100V Input 50mA Output Low-Dropout Voltage Regulator with HVSSOP-8 Package

Detail produk:

Tempat asal:	CN
Nama merek:	Original Factory
Sertifikasi:	Lead free / RoHS Compliant
Nomor model:	TPS7A4001DGNR

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	10
Harga:	Contact for Sample
Kemasan rincian:	HVSSOP-8
Waktu pengiriman:	5-8 Hari Kerja
Syarat-syarat pembayaran:	T/T, L/C, Western Union

Kontak

TPS7A4001DGNR 100V Input 50mA Output Low-Dropout Voltage Regulator with HVSSOP-8 Package

Deskripsi

Nomor bagian:	TPS7A4001DGNR	Tegangan - input (maks):	100V
Dropout tegangan (maks):	1.3V @ 50mA	Saat ini - Keluaran:	50mA
Psrr:	65dB (100Hz)	Suhu Operasional:	-40°C ~ 125°C

TPS7A4001DGNR Integrated Circuit Chip 100V 50mA Low-Dropout Voltage Regulator HVSSOP-8 Linear Regulator

Product Overview

The TPS7A4001DGNR is a very high voltage-tolerant linear regulator featuring a thermally-enhanced HVSSOP package, capable of withstanding continuous DC or transient input voltages up to 100V.

Technical Specifications

Product Category	LDO Voltage Regulators
Mounting Style	SMD/SMT
Package / Case	MSOP-8
Output Current	50 mA
Number of Outputs	1 Output
Polarity	Positive
Quiescent Current	25 uA
Output Type	Adjustable
Minimum Operating Temperature	-40 ℃
Maximum Operating Temperature	+125 ℃
Dropout Voltage	290 mV
Line Regulation	0.03 %/ Vout
Load Regulation	0.31 %/V
Operating Supply Current	20 uA
Output Voltage Range	1.175 V to 90 V
Power Dissipation	833 mW

Key Features

Very High Maximum Input Voltage: 100 V
Wide Input Voltage Range: 7 to 100 V
Accuracy: Nominal 1%, Over Line, Load, and Temperature: 2.5%
Low Quiescent Current: 25 µA
Quiescent Current at Shutdown: 4.1 µA
Maximum Output Current: 50 mA
CMOS Logic-Level-Compatible Enable Pin
Adjustable Output Voltage from about 1.175 to 90 V
Stable With Ceramic Capacitors: Input ≥ 1 µF, Output ≥ 4.7 µF
Dropout Voltage: 290 mV
Built-In Current Limit and Thermal Shutdown Protection
Package: High Thermal Performance HVSSOP PowerPAD™
Operating Temperature Range: -40°C to 125°C

Applications

Microprocessors and Microcontrollers Powered by Industrial Busses With High Voltage Transients
Industrial Automation
Telecom Infrastructure
Automotive
Power over Ethernet (PoE)
LED Lighting
Bias Power Supplies
