MCS1803GS-20-Z Linear Hall-Effect Current Sensor IC with ±2.5% Accuracy, 20A Current Sensing, and 100kHz Frequency

MCS1803GS-20-Z Linear Hall-Effect Current Sensor IC with ±2.5% Accuracy, 20A Current Sensing, and 100kHz Frequency
MCS1803GS-20-Z Linear Hall-Effect Current Sensor IC with ±2.5% Accuracy, 20A Current Sensing, and 100kHz Frequency

Gambar besar :  MCS1803GS-20-Z Linear Hall-Effect Current Sensor IC with ±2.5% Accuracy, 20A Current Sensing, and 100kHz Frequency

Detail produk:
Tempat asal: CN
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: MCS1803GS-20-Z
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: SOIC-8
Waktu pengiriman: 5-8 Hari Kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

MCS1803GS-20-Z Linear Hall-Effect Current Sensor IC with ±2.5% Accuracy, 20A Current Sensing, and 100kHz Frequency

Deskripsi
Nomor bagian: MCS1803GS-20-Z Saat ini - Penginderaan: 20A
Jumlah Saluran: 1 Kepekaan: 100mV/A
Frekuensi: 100kHz Linearitas: ±0,5%

MCS1803GS-20-Z Sensor IC 5V Linear Hall-Effect Current Sensor With ±2.5% Accuracy Over Temperatures
Product Description

The MCS1803GS-20-Z is a linear Hall-effect current sensor designed for AC or DC current sensing applications. The sensor features a differential Hall array that effectively cancels out stray magnetic fields for improved accuracy.

A low-resistance primary conductor allows current to flow in close proximity to the IC, which incorporates high-accuracy Hall-effect sensors. This current generates a magnetic field that is detected at two distinct points by integrated Hall-effect transducers. The magnetic field difference between these points is converted into a voltage proportional to the applied current. The device employs a spinning current technique to achieve low stable offset.

Galvanic isolation between the primary conductive path pins and sensor leads enables the MCS1803 to replace opto-isolators or other isolation devices in various applications.

Specifications
Current Rating: 20 A
Sensor Type: Current Sense
Response Time: 5 μs
Operating Supply Voltage: 5 V
Output Type: Analog
Length: 5 mm
Maximum Operating Temperature: +125°C
Minimum Operating Temperature: -40°C
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 4.5 V
Type: Hall-Effect Based Linear
Width: 4 mm
Features
  • 5V Single Supply Operation
  • Immune to External Magnetic Fields through Differential Sensing
  • 2.2kVRMS Minimum Isolation Voltage
  • Operating Temperature Range: -40°C to +125°C
  • 0.9mΩ Internal Conductor Resistance
  • 5A to 50A Sensing Range
  • Adjustable Bandwidth Up to 100kHz
  • 4μs Output Rising Time
  • Ratiometric Output from Supply Voltage
  • Output Proportional to AC or DC Currents
  • Factory-Trimmed for High Accuracy
  • No Magnetic Hysteresis
  • Integrated Shield Suppressing Capacitive Coupling (up to 10V/ns)
  • Available in SOIC-8 Package
Applications
  • Motor Controls
  • Automotive Systems
  • Load Detection and Management
  • Switch-Mode Power Supplies
  • Overcurrent Fault Protection
