ADM2484EBRWZ RS-485 Transceiver Integrated Circuit Chip with 500kbps Data Rate 5000Vrms Isolation and ±15kV ESD Protection

ADM2484EBRWZ RS-485 Transceiver Integrated Circuit Chip with 500kbps Data Rate 5000Vrms Isolation and ±15kV ESD Protection
ADM2484EBRWZ RS-485 Transceiver Integrated Circuit Chip with 500kbps Data Rate 5000Vrms Isolation and ±15kV ESD Protection

Gambar besar :  ADM2484EBRWZ RS-485 Transceiver Integrated Circuit Chip with 500kbps Data Rate 5000Vrms Isolation and ±15kV ESD Protection

Detail produk:
Tempat asal: CN
Nama merek: Original Factory
Sertifikasi: Lead free / RoHS Compliant
Nomor model: ADM2484EBRWZ
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 10
Harga: Contact for Sample
Kemasan rincian: SOIC-16
Waktu pengiriman: 5-8 hari kerja
Syarat-syarat pembayaran: T/T, L/C, Western Union
Kontak

ADM2484EBRWZ RS-485 Transceiver Integrated Circuit Chip with 500kbps Data Rate 5000Vrms Isolation and ±15kV ESD Protection

Deskripsi
Nomor Bagian: ADM2484EBRWZ Tegangan - Isolasi: 5000Vrms
Kecepatan Data: 500kbps Imunitas Sementara Mode Umum (Min): 25kV/µs
Tegangan - Pasokan: 3.3V, 5V Suhu Operasional: -40 ° C ~ 85 ° C.

ADM2484EBRWZ Integrated Circuit Chip 500kbps Full/Half Duplex RS-485 Transceiver SOIC-16
Product Description

ADM2484EBRWZ is an isolated data transceiver with ±15 kV ESD protection suitable for high speed, half- or full-duplex communication on multipoint transmission lines. For half-duplex operation, the transmitter outputs and receiver inputs share the same transmission line. Transmitter Output Pin Y links externally to Receiver Input Pin A, and Transmitter Output Pin Z links externally to Receiver Input Pin B.

Specifications
Product Category: Digital Isolators
Mounting Style: SMD/SMT
Package / Case: SOIC-16
Number of Channels: 3 Channel
Polarity: Unidirectional
Data Rate: 500 kb/s
Isolation Voltage: 5000 Vrms
Isolation Type: Galvanic Isolation
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 3 V
Operating Supply Current: 2 mA
Propagation Delay Time: 700 ns
Minimum Operating Temperature: -40℃
Maximum Operating Temperature: +85℃
Duplex: Half/Full Duplex
Forward Channels: 2 Channel
Maximum Fall Time: 1.1 us
Maximum Rise Time: 1.1 us
Product Type: Digital Isolators
Protocol Supported: RS-485, RS-422
Key Features
  • Isolated, RS-485/RS-422 transceiver, configurable as half- or full-duplex
  • ±15 kV ESD protection on RS-485 input/output pins
  • 500 kbps data rate
  • Complies with ANSI TIA/EIA RS-485-A-1998 and ISO 8482: 1987(E)
  • Suitable for 5 V or 3.3 V operation (VDD1)
  • High common-mode transient immunity: >25 kV/μs
  • True fail-safe receiver inputs
  • 256 nodes on the bus
  • Thermal shutdown protection
  • Operating temperature range: −40°C to +85°C
  • Wide body, 16-lead SOIC package
Applications
  • Isolated RS-485/RS-422 interfaces
  • Industrial field networks
  • INTERBUS
  • Multipoint data transmission systems
